World's smallest 160,000Nm Torque Limiter

Tandler Precision Ltd News and PR from Tandler Precision Ltd - Published 07 March 2013 The best thing about the new ST torque limiters from R+W is not only do they offer distinct benefits over shear pin and hydraulic alternatives.
These torque limiters are also lighter in weight making assembly easier and quicker. They are easily adjustable and can be serviced in situ. Yet even with all these attributes these newcomers have been introduced at a highly economical price.

The best thing about the new ST torque limiters from R+W is not only do they offer distinct benefits over shear pin and hydraulic alternatives they are also smaller than other mechanical torque limiters rated for up to 160,000 Nm. And their merits don’t stop there. These torque limiters are also lighter in weight making assembly easier and quicker.
They are easily adjustable and can be serviced in situ. Yet even with all these attributes these newcomers have been introduced at a highly economical price.
Now available from sole UK distributor Tandler, the ST torque limiter is up to 23% more compact, with respect to outer diameter at a given torque, by comparison with its mechanical competitors. The difference in overall coupling weight in the most extreme case is one ton. As a result, considerably greater circumferential speed is possible. So in terms of physical size, weight and maximum operating speed the ST is a star performer.

The size factor in particular makes the ST torque limiter very much easier to install. A lighter weight drive line that can be pre-assembled is another clear benefit. Lower overall weight also reduces mass moment of inertia as a consequence of lower flywheel mass. In addition to shortening the acceleration and braking processes, the system therefore achieves greater dynamics. This in turn translates into higher productivity.
A shear pin coupling by comparison may cost less but it requires considerably more time to install, adjust and put into operation. It also demands heavy duty and specialist maintenance, a factor that is especially pronounced in the event of a stoppage. And whilst a hydraulic overload coupling has the advantage of being extremely compact this is counterbalanced by the need for complicated procedures following overload and the significant potential of oil contamination to nearby components.

In designing its ST torque limiters, R+W examined and addressed all these disadvantages. The R+W operating principle utilises disc springs, allowing the ST’s immediate re-engagement following a stoppage. There is no need to replace any expendable parts like pins or valves. Furthermore its disengagement does not result in hydraulic oil being sprayed onto adjacent components.

The most important factor of all is that the ST torque limiter is 100% reliable. Thanks to R+W’s patented spring-loaded ball detent design, the coupling will disengage at exactly the same torque, again and again. The disengagement value is easily set via the torque adjustment range that is engraved on the body of the coupling.
World's smallest 160,000Nm Torque Limiter
