High
Quality High Precision Parts and Components |
BDC Engineering (BDCE)
is a highly established precision engineering company in the North
West of England.
With over forty years of combined experience in the industry we are
able cater to a wide range of industrial sectors across the country
supplying them with high quality precision machined components
produced by our highly qualified machinists.
BDCE aims to provide its customers with a comprehensive and reliable
precision engineering service so whether you require just a one off
prototype or low to high volume production we are here to provide a
solution.
From initial contact and design through to inspection and delivery
BDCE provides a wide range of machining and fabrication services
including but not limited to: |
..Precision Grinding |
BDCE offers a
comprehensive precision grinding service including surface grinding and shaft
grinding both internal and external.
- Ribbon RUR 1000 Universal Grinder
- Elliot 925 Hydraulic Surface
Grinder |
..Precision
CNC Turning |
BDCE offers a complete
range of precision cnc turning facilities ready to undertake any type of turning
work that comes our way, from 1off through to 10,000 + off on our up
to date multi bar feed CNC lathes.
We also use a range of conventional lathes which are more suited for
one offs or prototype work so whatever your turning requirements are
we will provide you with the perfect solution.
Turning
capacity:
Colchester Tornado 80 Capacity with max 42mm through spindle
- multi bar feed - parts catcher - multi bore collet system -12 station turret
Colchester Tornado 110 Capacity max 51mm through spindle -
multi bar feed - parts catcher - programmable tailstock - swarf
conveyor - multi bore collet system - 12 station turret
Colchester Tornado 200 Capacity max 65mm through spindle -
multi bar feed - parts catcher - programmable tailstock - 12 station turret
Colchester Tornado A50 Capacity max 42mm through spindle -
multi bar feed - parts catcher - multi bore collet system - 12
station turret
Colchester 2000L - 1150mm between centres - 230mm swing over
saddle - 4 station turret
Takisawa CNX540 - 1100mm between centres x 300 mmm swing over
saddle - 6 station rear turret - 4 station front turret
Conventional lathe equipment - Includes 2 ward capstan lathes
- EMI-MEC E Sprint pegboard - Colchester Centre Lathe with DRO - Tos
Centre Lathe with DRO
Doosan Lynx 2100LB - Maximum turning diameter of 350mm -
Maximum turning length of 550mm - 12 station turret - 10" power
chuck - Hydraulic programmable tailstock |
..Precision
CNC Milling |
Our manufacturing
facility based in Ellesmere Port houses a range of vertical and
horizontal precision cnc milling machines including both CNC and conventional with DRO enabling BDCE to offer a complete milling machining service to
cover the whole of the country.
Milling capacity:
- 2 off CNC Wenlock V5/8 vertical
milling machine with 4th axis capabilities
- Odessa CNC universal milling
machine
- Matchmaker vertical Knee Type
milling machine
- Conventional Elgar universal
milling machine
- Astra horizontal milling machine
- 4th axis full contouring 8" chuck) |
..Fabrication |
BDCE also has the
ability to offer a fabrication service including:
- Welding TIG, MIG, ARC for mild
steel, stainless steel and aluminium
- Edwards True Cut Guillotine
- Pearson 70 ton press brake
This is only a small description of the wide range of engineering services BDCE is able to provide so if you would like to
find out more or request a quotation please feel free to get in
touch, alternatively please head over to our website, thank you. |
